Rotary Lobe Pumps (VX 100-64Q)
The Rotary Lobe Transfer Pump VX 100-64Q is a light-weight transportable positive displacement pump with multipurpose usages for various oil recovery applications e.g. several types of skimmers. It can also be used as an off-loading pump.
How it works
The transfer pump has a capacity of 20 m3/h (77 GPM) and it can handle solids of up to 19 mm (0.75 in) and has a self-priming suction lift of up to 7.62 m (25 ft). Its compact size and high performance make it ideal for off-loading medium viscous oils with debris or contaminated, emulsified oil-water mixtures on site. The Rotary Lobe principal ensures that the pump has sensitive shear characteristics, giving smooth pumping action and pulsation-free operation to avoid further emulsification. The pump is manufactured in cast iron with an aluminum pump casing and is fitted with an oil-resistant rubber lobe rotor for maximum performance. The pump noise output is only 78 dB and is fitted with a hydraulic motor for extended use and reliability. Standard hydraulic connectors: pressure 1/2″ Tema 5011 (female), return 1/2″ Tema 5021 (male), standard discharge outlet 3″ Camlock (male).
Features
- Light-weight and transportable
- Multipurpose usage for various oil recovery applications
- Sea water resistant aluminum with aluminum frame
Scenarios of use
- Inland
- Rivers
- Harbors, ports & terminals
- Shoreline
- Offshore
Related equipment
| Technical Specifications | LPSC 330 | S-series | VX 100-64Q |
|---|---|---|---|
| Item ID | 397867 | 403003 | 218534 |
| Length | 1850 mm / 72.8 in | 635 mm (25 in) | 473 mm / 18.6 in |
| Width | 700 mm / 27.5 in | 254 mm (10 in) | 168 mm / 6.6 in |
| Height | 1480 mm / 58.3 in | 457 mm (18 in) | 315 mm / 12.4 in |
| Weight | 750 kg / 1653 lbs | 19 kg (42 lbs) | 48 kg / 105 lbs |
| Capacity | 334 m³/h* / 1471 gpm* | 37 m3/h (165 gpm) | 20 m³/h* / 86 gpm* |
| Engine | Deutz D2011L04i | - | - |
| Pump | Victor S 160 | - | - |
| Total Head | 40 m / 131ft | - | - |
| Power | - | 2.9 kw (4 hp) | 9 kW / 12 hp |
| Coupling Size | - | 51 mm (2 in) | - |
| Engine Type | - | Gas | - |
| Hydraulic flow (skimmer) | - | - | 40 l/min / 10.7 gpm |
| Hydraulic pressure | - | - | 135 bar / 1958 psi |
| Discharge pressure | - | - | 5 bar / 72.5 psi |
| Solids handling | - | - | 19 mm / 0.75 in |
