Multimax 50

The Multimax LAM 50 is a brush chain-type free-floating oil skimmer designed to recover oil in fast-flowing rivers, oil ponds, harbors or as an advancing side sweep skimmer. The skimmer can be used in all terrains and environments, including Arctic conditions. The one 3-row oleophilic V-brush chain bank separates the oil from the water effectively and lifts it to the specially designed brush cleaner from where the oil is directed to the oil transfer pump. The skimmer has a special flow design to improve oil recovery in stationary conditions. The double rotation direction capability enhances the recovery of light to heavy viscous oils. The skimmer has robust detachable aluminum floats, aluminum frame and single lifting point making it easy to lift, operate, clean and store. The LAM 50 skimmer with its standard heated scraper and hopper makes it an effective skimming unit in Arctic conditions, which has been tested at Ohmsett testing facilities. The skimmer has been deployed effectively in several oil recovery operations worldwide. During certified capacity tests, conducted by Bureau Veritas, a recovery rate of 51.2 m³/h (225 GPM) was achieved.

Technical Specifications
Item ID
1800 mm / 71 in
1416 mm / 56 in
1251 mm / 49 in
230 kg / 507 lbs
402 mm / 16 in
51.2 m3/h / 225 gpm
Free water collected
Hydraulic flow (skimmer)
15 l/min / 4 gpm
Hydraulic pressure
150 bar / 2175 psi
4.0 kW / 5.3 hp
Suitable pumps
GTA 20-70, VX 64/128
Special Features

Suitable for recovery of all oil types including weathered crude

Enhanced recovery due to brush rotation in both direction

Enhanced oil flow due to special design

Heated scraper for use in arctic

Robust and durable aluminum construction

Detachable floats make cleaning and storage easy

ASTM connectors in front makes fixing of sweep boom easy

Single point lifting
